PRIMERGY RX4770 M4 Rack Server

The FUJITSU Server PRIMERGY RX4770 M4 defines four-socket rack server technology without compromising performance, scalability, and expandability.
Manufacturer Fujitsu
Part Number(s): RX4770-M4

Adirondack Networks offers complete configurations as well as individual parts and upgrades for this model. For pricing on new or refurbished PRIMERGY RX4770 M4 Rack Servers, upgrades or parts, please contact us.
RX4770-M4-600px-1 RX4770-M4-600px-2

About the PRIMERGY RX4770 M4 Rack Server

Chipset

  • Intel C624

Mainboard Type

  • D3753

Product Type

  • Quad Socket Rack Server

Processor

  • Intel Xeon Processor Scalable Family

Memory

  • 16 GB - 6 TB, DIMM (DDR4)

Memory Protection

  • Advanced ECC
  • Memory Scrubbing
  • SDDC
  • Rank sparing memory support
  • Memory Mirroring support
  • DDDC (Double Device Data Correction)

Drives (Optional)

  • DVD supermulti
  • Ultraslim
  • SATA I

PCI-Express 3.0 x16

  • 8 x whereas 4x full height and 4x low profile with up to 167mm length

Slot Notes

  • 4 PCIe slots are supported with the first and second processor. Additional 4 PCIe slots are supported with the third and forth processors
  • Slot 1&2: PCIe Gen3 x16 @CPU1 for low profile cards with up to 167mm length
  • Slot 3&4: PCIe Gen3 x16 @CPU4 for full height cards with up to 167mm length
  • Slot 5: PCIe Gen3 x16 @CPU2 for low profile cards with up to 167mm length
  • Slot 6&7: PCIe Gen3 x16 @CPU3 for full height cards with up to 167mm length
  • Slot 8: PCIe Gen3 x16 @CPU2 for low profile cards with up to 167mm length (used for the internal modular RAID controller if selected)

Optional Accessible Drives

  • 1 x 5.25/9.5mm for DVD-RW/Blu-ray
  • All possible options described in relevant system configurator

Storage Drive Bays

  • 2.5-inch hot-plug SAS/SATA/PCIe
  • 2 x M.2 slot whereas slot 1 supports 80mm or 110mm and slot 2 supports 42mm or 80mm
  • 16 x 2.5-inch hot-plug SAS/SATA/PCIe
  • 8 x 2.5-inch hot-plug SAS/SATA/PCIe

I/O Controller Onboard

  • Intel C624, 1 x SATA channel for ODD
  • DynamicLoM based on Intel C624 (Intel X722)
  • Optional DynamicLoM OCP adaptors:, 2 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 1 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s SFP+
  • Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller), IPMI 2.0 compatible

Trusted Platform Module (TPM)

  • Infineon / TPM 1.2 or TPM 2.0 module; TCG compliant (option)

Power Supply Configuration

  • 2 hot-plug power supplies (standard), single power supply configuration possible

Active Power

  • 2,189 W

Rack (W x D x H)

  • 482.6 mm (Bezel) / 434.8 mm (Body) x 724.8 x 86.9 mm

Mounting Depth Rack

  • 741.3 mm

Weight

  • Up to 30.3 kg
