About the Oracle Sun SPARC T4-1 Server

Component List

BATTERIES
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
n/a	371-2210 [C]	3V Lithium Coin Cell Battery	n/a

CABLES
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
7102869	7039990 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 10M	n/a
7102870	7039999 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 20M	n/a
7102871	7040001 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 50M	n/a
X2121A-1M-N	530-4444 [C]	10Gbps QSFP to QSFP Cable, 1m	n/a
X2121A-2M	530-4567 [C]	10Gbps QSFP to QSFP Cable, 2m	n/a
X2121A-3M-N	530-4445 [C]	10Gbps QSFP to QSFP Cable, 3m	n/a
X2121A-5M-N	530-4446 [C]	10Gbps QSFP to QSFP Cable, 5m	n/a
X2130A-1M-N	530-4441 [C]	10Gbps SFP+ TwinX Cable, 1m	n/a
X2130A-3M-N	530-4442 [C]	10Gbps SFP+ TwinX Cable, 3m	n/a
X2130A-5M-N	530-4443 [C]	10Gbps SFP+ TwinX Cable, 5m	n/a
SE3X4A11Z 4 [S]	594-6778	SAS Cable Kit	n/a
SE3X4A11Z 4 [S]	530-3891	4x Mini SAS Cable, SFF-8087 to SFF-8087, 450mm	n/a
X2130A-10M-N [S]	530-4454 [C]	10Gbps SFP+ TwinX Cable, 10m	n/a
n/a	560-2959 [F]	Cable Kit	n/a
	530-4373	34-Pin Connector Board to Fan Board Signal Cable	n/a
	530-4378	26-Pin System Board to PDB Cable	n/a
	530-4418	4x Mini SAS Cable, SFF-8087 to 90° SFF-8087, 345mm	n/a
	530-4466	3-Pin Vertical to Horizontal PDB Power Cable	n/a
	371-2484 1	PDB Signal Cable	n/a
	530-4490	SATA Cable, 90° SATA to 90° SATA, 450mm	n/a
	530-3891	4x Mini SAS Cable, SFF-8087 to SFF-8087, 450mm	n/a
	530-4377	34-Pin System Board to PDB Cable	n/a
	530-4417	6-Pin Fan Power Cable	n/a
	530-4419	4x Mini SAS Cable, SFF-8087 to 90° SFF-8087, 450mm	n/a
n/a	7076188 [F]	Cable Kit	560-2959 [F]
	530-4373	34-Pin Connector Board to Fan Board Signal Cable	n/a
	530-4377	34-Pin System Board to PDB Cable	n/a
	530-4378	26-Pin System Board to PDB Cable	n/a
	530-4417	6-Pin Fan Power Cable	n/a
	530-4418	4x Mini SAS Cable, SFF-8087 to 90° SFF-8087, 345mm	n/a
	530-4419	4x Mini SAS Cable, SFF-8087 to 90° SFF-8087, 450mm	n/a
	530-4466	3-Pin Vertical to Horizontal PDB Power Cable	n/a
	371-2484 2	PDB Signal Cable	n/a
	530-4490	SATA Cable, 90° SATA to 90° SATA, 450mm	n/a
	530-3891	4x Mini SAS Cable, SFF-8087 to SFF-8087, 450mm	n/a
n/a	7080857 [F]	Cable Kit	n/a
	530-4373	34-Pin Connector Board to Fan Board Signal Cable	n/a
	530-4377	34-Pin System Board to PDB Cable	n/a
	530-4378	26-Pin System Board to PDB Cable	n/a
	530-4417	6-Pin Fan Power Cable	n/a
	530-4418	4x Mini SAS Cable, SFF-8087 to 90° SFF-8087, 345mm	n/a
	530-4419	4x Mini SAS Cable, SFF-8087 to 90° SFF-8087, 450mm	n/a
	530-4490	SATA Cable, 90° SATA to 90° SATA, 450mm	n/a
	371-2484 3	PDB Signal Cable	n/a
	530-4466	3-Pin Vertical to Horizontal PDB Power Cable	n/a
	530-3891	4x Mini SAS Cable, SFF-8087 to SFF-8087, 450mm	n/a

1 This part is also included in the cable kit FRU packaged part
2 This part is also included in the cable kit FRU packaged part
3 This part is also included in the cable kit FRU packaged part

COMMUNICATION
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
7104074	7092757 [C]	Dual 40Gb/Sec (4x) QDR InfiniBand Host Channel Adapter Module M3	n/a
X4242A	375-3696 [C]	Dual 40Gbps InfiniBand 4x QDR PCI Express Low Profile Host Channel Adapter	n/a
X4242A	7092767 [C]	Dual 40Gbps InfiniBand 4x QDR PCI Express Low Profile Host Channel Adapter	n/a
X6000A 5 [S]	375-3424 [C]	PCI Express Sun Crypto Accelerator 6000	n/a
X6000A-N [S]	375-3424 [C]	PCI Express Sun Crypto Accelerator 6000	n/a
n/a	7046442 [C]	Dual 40Gb/Sec (4x) QDR InfiniBand Host Channel Adapter Module M3	n/a

5 Option X6099A (IPsec enabler CD) is required to enable the adapter's support for IPsec acceleration

DISK BACKPLANE
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
n/a	511-1435 [F]	8-Slot Disk Backplane	n/a
n/a	7053717	8-Slot Disk Backplane Assembly	n/a
n/a	330-5301	Grey 2U Backplane Retainer Clip	n/a

DISKS
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
7107550	7077233 [C]	400GB Solid State SATA Drive Assembly	n/a
	7076379	400GB 2.5" SATA-3 Solid State Drive Intel SSDSC2BA400G3S [ITVSC2BA3SUN400]	n/a
	541-2123	Marlin 2.5" Bracket	n/a
SE6X3K11Z	542-0287 [C]	600GB - 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks;	n/a
	390-0488	Hitachi HUC106060CSS600 [H106060SDSUN600G] (600GB - 10000 RPM - SAS Disk)	n/a
	390-0491	Seagate ST9600205SS [ST960005SSUN600G](600GB 10000 RPM SAS Disk)	n/a
	7045228	Hitachi HUC109060CSS600 [H109060SESUN600G] (600GB - 10000 RPM - SAS Disk)	n/a
	541-2123	Marlin 2.5" Bracket	n/a
7101423 [S]	7017183 [C]	100GB Solid State SATA Drive Assembly	n/a
	7017177	Intel SSDSA2BZ100G3 [Inquiry Unknown] (100GB - 2.5" Solid State - SATA Disk)	n/a
	541-2123	Marlin 2.5" Bracket	n/a
7101469 [S]	7017184 [C]	300GB Solid State SATA Drive Assembly	n/a
	7017181	Intel SSDSA2BZ300G3 [Inquiry Unknown] (300GB - 2.5" Solid State - SATA Disk)	n/a
	541-2123	Marlin 2.5" Bracket	n/a
SE6X3G12Z [S]	542-0388 [C]	300GB - 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0487	Hitachi HUC106030CSS600 [H106030SDSUN300G] (300GB - 10000 RPM - SAS Disk)	n/a
	390-0490	Seagate ST9300605SS [ST930005SSUN300G](300GB 10000 RPM SAS Disk)	n/a
	7045226	Hitachi HUC109030CSS600 [H109030SESUN300G] (300GB - 10000 RPM - SAS Disk)	n/a
	541-2123	Marlin 2.5" Bracket	n/a

ETHERNET
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
7100477	7070195 [C]	Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP	7048474 [C]
7100481	7070202 [C]	Dual Port GbE PCI Express 2.0 Low Profile Adapter, MMF	7014747 [C]
7100488	7070006 [C]	Dual 10-Gigabit Base-T PCI Express Gen2	7014776 [C]
SE3X7XA1Z	501-7489 7 [C]	10GbE XAUI Card	n/a
SE3X7XT1Z	375-3301 [C]	10Gb/sec XFP Optical Transceiver Multi Mode Short Range (SR)	n/a
SE3X7XT1Z	7058828 [C]	10Gb/sec XFP Optical Transceiver Multi Mode Short Range (SR)	375-3301 [C]
X1109A-Z	7051223 [C]	Dual 10-Gigabit PCI Express Ethernet SFP+ LP	375-3617 [C]
X2124A-N	7326504 [C]	10Gbps QDR InfiniBand/40Gbps Ethernet QSFP Transceiver	135-1204 [C]
X2129A-N	530-4449 [C]	10Gb/Sec Short Wave SFP+ Transceiver	n/a
X5562A-Z	135-1205 [C]	10Gb/Sec Long Wave SFP+ Transceiver	n/a
7105381 [S]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - SR
7105381 [S]	7053422 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - SR	375-3681 [C]
7105382 [S]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - Direct Attach
7105382 [S]	7053423 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - Direct Attach	375-3682 [C]
SE3X7XT2Z [S]	375-3495 [C]	10Gb/Sec XFP Optical Transceiver Single Mode Long Range (LR)	n/a
SG-XPCIEFCOE2-Q-SR [S]	7053422 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - SR	375-3681 [C]
SG-XPCIEFCOE2-Q-TA [S]	7053423 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - Direct Attach	375-3682 [C]
X4447A-Z-N [S]	7055021 [C]	Quad Port GbE PCI Express, UTP	511-1422 [C]
X4447A-Z-N [S]	371-2207	Bracket Low-Profile	n/a
X7281A-2-N [S]	7056733 [C]	PCI Express Dual Gigabit Ethernet MMF	371-0904 [C]
n/a	135-1204 [C]	10Gb/Sec QDR InfiniBand / 40Gb/Sec Ethernet QSFP Transceiver	n/a
n/a	371-0904 [C]	PCI Express Dual Gigabit Ethernet MMF	n/a
n/a	375-3617 [C]	Dual 10-Gigabit Ethernet SFP+ LP	n/a
n/a	375-3681 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - SR	n/a
n/a	375-3682 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - Direct Attach	n/a
n/a	511-1422 [C]	Quad Port GbE PCI Express, UTP	n/a
n/a	371-2207	Bracket Low-Profile	n/a
n/a	7014741 [C]	Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP	n/a
n/a	7014747 [C]	Dual Port GbE PCI Express 2.0 Low Profile Adapter, MMF	n/a
n/a	7014776 [C]	Dual 10-Gigabit Base-T PCI Express Gen2	n/a
n/a	7048474 [C]	Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP	7014741 [C]

7 Requires one XFP Transceiver

FAN
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
n/a	541-4124 [F]	Fan Board Assembly	n/a
	330-5243	Fan Board Cover	n/a
	511-1434	Fan Board	n/a
n/a	541-4222 [C]	Fan Assembly	n/a
n/a	371-4613	60×28mm 10400/9500 RPM Dual Fan	n/a

FIBRE CHANNEL
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
7101674	7023303 [C]	Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, QLogic	n/a
7101676	7023325 [C]	Pair of 16Gbps Short Wave SFP+	n/a
7101676	7023324	16Gb/Sec Short Wave SFP+ Transceiver, QLogic	n/a
7101678	7023315 [C]	Pair of 10Gbps Short Wave SFP+	n/a
7101678	7023316	10Gb/Sec Short Wave SFP+ Transceiver, QLogic	n/a
7101684	7023036 [C]	Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, Emulex	n/a
7101686	7023059 [C]	Pair of 16Gbps Short Wave SFP+	n/a
7101686	7023053	16Gb/Sec Short Wave SFP+ Transceiver, Emulex	n/a
7105392	8Gigabit/Sec PCI Express Dual FC Host Adapter for EU Countries
7105392	7053434 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter, Emulex	371-4306 [C]
SG-XPCIE2FC-QF8-N 9	371-4325 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	n/a
7101688 [S]	7023057 [C]	Pair of 10Gbps Short Wave SFP+	n/a
7101688 [S]	7023046	10Gb/Sec Short Wave SFP+ Transceiver, Emulex	n/a
SG-XPCIE2FC-EM8-N 10 [S]	7053434 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter, Emulex	371-4306 [C]
n/a	371-4306 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	n/a

9 Recommended that this card be installed in upper slots 3, 4, or 5
10 Recommended that this card be installed in upper slots 3, 4, or 5

I/O
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
n/a	541-4084 [C]	2-Slot X8/XAUI Riser Assembly	n/a
	341-4139	PCI Filler Panel	n/a
	350-1413	PCI Express Riser	n/a
	511-1613	XAUI Riser	n/a
n/a	541-4085 [C]	2-Slot X8/X16 PCI Express Riser Assembly	n/a
	341-4139	PCI Filler Panel	n/a
	511-1614	PCI Express Riser	n/a
	541-2531	Bracket	n/a
n/a	7047128 [C]	2-Slot X8/XAUI Riser Assembly	541-4084 [C]
	341-4139	PCI Filler Panel	n/a
	350-1413	PCI Express Riser	n/a
	7047129	XAUI Riser	511-1613
n/a	7047131 [C]	2-Slot X8/X16 PCI Express Riser Assembly	541-4085 [C]
	341-4139	PCI Filler Panel	n/a
	541-2531	Bracket	n/a
	7047178	PCI Express Riser	511-1614

MEMORY
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
7104199	16GB Memory Expansion (1 × 16GB) Option
7104199	7042210 [C]	16GB DDR3L-1600/PC3L-12800 DIMM (runs at 1066 MHz)	n/a
7104201	32GB Memory Expansion (1 × 32GB) Option
7104201	7042211 [C]	32GB DDR3L-1066/DDR3L-1333 DIMM	n/a
7101696 [S]	8GB Memory Expansion (2 × 4GB) Option
7101696 [S]	7014642 [C]	4GB DDR3L-1333/PC3L-10600 DIMM	n/a
7101697 [S]	16GB Memory Expansion (2 × 8GB) Option
7101697 [S]	7014640 [C]	8GB DDR3L-1333/PC3L-10600 DIMM	n/a
7101698 [S]	32GB Memory Expansion (2 × 16GB) Option
7101698 [S]	7020577 [C]	16GB DDR3L-1066/PC3L-10600 DIMM	n/a
7104197 [S]	8GB Memory Expansion (1 × 8GB) Option
7104197 [S]	7042208 [C]	8GB DDR3L-1600/PC3L-12800 DIMM	n/a

MISCELLANEOUS
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
n/a	350-1562	Clear Plastic Air Duct	n/a

POWER
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
n/a	300-2235 [C]	Type A249 1100/1200 Watt AC Input Power Supply	n/a
n/a	300-2304 [C]	Type A249A 1100/1200 Watt AC Input Power Supply	300-2235 [C]
n/a	541-4223 [F]	Power Distribution Assembly	n/a
	341-3166	Bus Bar Left	n/a
	341-3167	Bus Bar Right	n/a
	511-1437	Horizontal Power Distribution Board	n/a
	371-2484 11	PDB Signal Cable	n/a
	511-1513	Vertical Power Distribution Board	n/a
n/a	7049253 [F]	Power Distribution Assembly	541-4223 [F]
	341-3166	Bus Bar Left	n/a
	341-3167	Bus Bar Right	n/a
	7049252	Vertical Power Distribution Board	n/a
	7051687	Horizontal Power Distribution Board	511-1437
	371-2484 12	PDB Signal Cable	n/a
n/a	7081590 [C]	Type A249A 1100/1200 Watt AC Input Power Supply	300-2304 [C]

11 This part is also included in the cable kit FRU packaged part
12 This part is also included in the cable kit FRU packaged part

RACK
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
n/a	371-2740 [C]	1U/2U Snap-In Slide Rail Rackmount Kit, 730mm	n/a
n/a	371-2742 [C]	1U/2U Cable Management Arm	n/a

REMOVABLE MEDIA
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
n/a	541-2732 [C]	USB Assembly	n/a
	330-4418	DVD Tray	n/a
	341-4072	DVD Filler Panel	n/a
	501-7698	USB Board	n/a
n/a	541-3493 [C]	Slot-Load SATA DVD-Writer/CD-Writer - USB Board Assembly	n/a
	330-5056	DVD Tray	n/a
	390-0442	8x Slot-Load SATA DVD-Writer/24x CD-Writer	n/a
	390-0443	8x Slot-Load SATA DVD-Writer/24x CD-Writer	n/a
	390-0454	8x SATA DVD Writer/24x CD-Writer	n/a
	390-0486	8x Slot-Load SATA DVD-Writer/24x CD-Writer	390-0443
	501-7698	USB Board	n/a
n/a	7057476 [C]	Slot-Load SATA DVD-Writer/CD-Writer - USB Board Assembly	n/a
	330-5056	DVD Tray	n/a
	501-7698	USB Board	n/a
	7045772	8x Slot-Load SATA DVD-Writer/24x CD-Writer	n/a
	7066500	DVD Tray	n/a
n/a	7070425 [C]	Slot-Load SATA DVD-Writer/CD-Writer - USB Board Assembly	n/a
	330-5056	DVD Tray	n/a
	501-7698	USB Board	n/a
	7045772	8x Slot-Load SATA DVD-Writer/24x CD-Writer	n/a
	7066500	DVD Tray	n/a
n/a	7079141 [C]	Tray-Load SATA DVD-Writer/CD-Writer - USB Board Assembly	n/a
	501-7698	USB Board	n/a
	7071296	8x Tray-Load SATA DVD-ROM Writer / 24x CD-ROM Writer	n/a
	7079137	DVD Tray	n/a
	7089963	8x Tray-Load DVD-ROM/24-x CD-ROM Writer (Gen5)	n/a
	7309891	8x Tray-Load DVD-ROM/24x CD-ROM Writer (Gen6)	n/a

SCSI
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
7105387	8-Port 6Gbps SAS-2 PCI Express HBA
7105387	7047853 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	375-3641 [C]
7107092	7069200 [C]	800GB PCI Express Flash Accelerator F80 SAS HBA	n/a
7104482 [S]	7070787 [C]	Flash Accelerator F40 400GB Solid State Memory	7026993 [C]
7105384 [S]	Dual-Channel Ultra320 LVD SCSI PCI Express Adapter for EU Countries
7105384 [S]	7050790 [C]	Dual-Channel Ultra320 LVD SCSI PCI Express Adapter	375-3357 [C]
SGX-SAS6-EXT-Z 13 [S]	7047853 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	375-3641 [C]
SGX-SAS6-R-INT-Z 14 15 [S]	7047503 [C]	8-Port 6Gbps SAS-2 RAID PCI Express HBA, B4 ASIC	375-3701 [C]
SGX-SAS6-R-INT-Z 14 15 [S]	7050794 [C]	6Gbps SAS-2 RAID PCI Battery Module, BBU08	371-4982 [C]
SGXPCIE2SCSIU320-N [S]	7050790 [C]	Dual-Channel Ultra320 LVD SCSI PCI Express Adapter	375-3357 [C]
n/a	371-4982 [C]	6Gbps SAS-2 RAID PCI Battery Module, BBU08	n/a
n/a	375-3357 [C]	Dual-Channel Ultra320 LVD SCSI PCI Express Adapter	n/a
n/a	375-3641 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	n/a
n/a	375-3701 [C]	8-Port 6Gbps SAS-2 RAID PCI Express HBA, B4 ASIC	n/a
n/a	7026993 [C]	Flash Accelerator F40 400GB Solid State Memory	n/a

13 For external cable routing reasons this card must be installed in slot 3, slot 4 or slot 5.
14 If SAS cabling for X-Option SGX-SAS6-R-INT-Z is needed, order X-Option SE3X4A11Z SAS Cable Kit.
15 For thermal reasons the RAID HBA needs to be in slot 3.

SYSTEM BOARD
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
n/a	7096741 [F]	8-Core 2.85GHz System Board Assembly (reworked 7047134)	n/a
	350-1440	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	7047135	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a
n/a	7096745 16 [F]	8-Core 2.85GHz System Board Assembly (reworked 7063388)	n/a
	350-1440	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	7063382	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a
n/a	7097402 [F]	8-Core 2.85GHz System Board Assembly (reworked 7015924)	n/a
	350-1440	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	7015696	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a
n/a	7321781 [F]	8-Core 2.85GHz System Board Assembly	n/a
	350-1440	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	7321738	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a
n/a	7015924 [F] [S]	8-Core 2.85GHz System Board Assembly	n/a
	350-1440	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	7015696	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a
n/a	7047134 [F] [S]	8-Core 2.85GHz System Board Assembly	7015924 [F] [S]
	350-1440	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	7047135	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a
n/a	7063388 17 [F] [S]	8-Core 2.85GHz System Board Assembly	n/a
	350-1440	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	7063382	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a

16 Requires System Firmware 8.4.2.d (or higher)
17 Requires System Firmware 8.4.2.d (or higher)

SYSTEM SERVICE PROCESSOR
OPTION #	MANUFACTURING PART #	DESCRIPTION	PREVIOUS PART #
n/a	541-4693 [C]	Service Processor Assembly	n/a
	350-1614	Service Processor Cover	n/a
	511-1336	AST2200 Service Processor	n/a
n/a	7053715 [C]	Service Processor Assembly	541-4693 [C]
	350-1614	Service Processor Cover	n/a
	7053714	AST2200 Service Processor	n/a

SPARC-T4-1 Component List

Batteries
Option #	Manufacturing Part #	Description	Previous Part #
n/a	371-2210 [C]	3V Lithium Coin Cell Battery	n/a

Cables
Option #	Manufacturing Part #	Description	Previous Part #
7102869	7039990 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 10M	n/a
7102870	7039999 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 20M	n/a
7102871	7040001 [C]	MPO to MPO High Bandwidth QSFP Optical Cable, 50M	n/a
X2121A-1M-N	530-4444 [C]	10Gbps QSFP to QSFP Cable, 1m	n/a
X2121A-2M	530-4567 [C]	10Gbps QSFP to QSFP Cable, 2m	n/a
X2121A-3M-N	530-4445 [C]	10Gbps QSFP to QSFP Cable, 3m	n/a
X2121A-5M-N	530-4446 [C]	10Gbps QSFP to QSFP Cable, 5m	n/a
X2130A-1M-N	530-4441 [C]	10Gbps SFP+ TwinX Cable, 1m	n/a
X2130A-3M-N	530-4442 [C]	10Gbps SFP+ TwinX Cable, 3m	n/a
X2130A-5M-N	530-4443 [C]	10Gbps SFP+ TwinX Cable, 5m	n/a
SE3X4A11Z 4 [S]	594-6778	SAS Cable Kit	n/a
SE3X4A11Z 4 [S]	530-3891	4x Mini SAS Cable, SFF-8087 to SFF-8087, 450mm	n/a
X2130A-10M-N [S]	530-4454 [C]	10Gbps SFP+ TwinX Cable, 10m	n/a
n/a	560-2959 [F]	Cable Kit	n/a
	530-4373	34-Pin Connector Board to Fan Board Signal Cable	n/a
	530-4378	26-Pin System Board to PDB Cable	n/a
	530-4418	4x Mini SAS Cable, SFF-8087 to 90° SFF-8087, 345mm	n/a
	530-4466	3-Pin Vertical to Horizontal PDB Power Cable	n/a
	371-2484 1	PDB Signal Cable	n/a
	530-4490	SATA Cable, 90° SATA to 90° SATA, 450mm	n/a
	530-3891	4x Mini SAS Cable, SFF-8087 to SFF-8087, 450mm	n/a
	530-4377	34-Pin System Board to PDB Cable	n/a
	530-4417	6-Pin Fan Power Cable	n/a
	530-4419	4x Mini SAS Cable, SFF-8087 to 90° SFF-8087, 450mm	n/a
n/a	7076188 [F]	Cable Kit	560-2959 [F]
	530-4373	34-Pin Connector Board to Fan Board Signal Cable	n/a
	530-4377	34-Pin System Board to PDB Cable	n/a
	530-4378	26-Pin System Board to PDB Cable	n/a
	530-4417	6-Pin Fan Power Cable	n/a
	530-4418	4x Mini SAS Cable, SFF-8087 to 90° SFF-8087, 345mm	n/a
	530-4419	4x Mini SAS Cable, SFF-8087 to 90° SFF-8087, 450mm	n/a
	530-4466	3-Pin Vertical to Horizontal PDB Power Cable	n/a
	371-2484 2	PDB Signal Cable	n/a
	530-4490	SATA Cable, 90° SATA to 90° SATA, 450mm	n/a
	530-3891	4x Mini SAS Cable, SFF-8087 to SFF-8087, 450mm	n/a
n/a	7080857 [F]	Cable Kit	n/a
	530-4373	34-Pin Connector Board to Fan Board Signal Cable	n/a
	530-4377	34-Pin System Board to PDB Cable	n/a
	530-4378	26-Pin System Board to PDB Cable	n/a
	530-4417	6-Pin Fan Power Cable	n/a
	530-4418	4x Mini SAS Cable, SFF-8087 to 90° SFF-8087, 345mm	n/a
	530-4419	4x Mini SAS Cable, SFF-8087 to 90° SFF-8087, 450mm	n/a
	530-4490	SATA Cable, 90° SATA to 90° SATA, 450mm	n/a
	371-2484 3	PDB Signal Cable	n/a
	530-4466	3-Pin Vertical to Horizontal PDB Power Cable	n/a
	530-3891	4x Mini SAS Cable, SFF-8087 to SFF-8087, 450mm	n/a

1 This part is also included in the cable kit FRU packaged part
2 This part is also included in the cable kit FRU packaged part
3 This part is also included in the cable kit FRU packaged part

Communication
Option #	Manufacturing Part #	Description	Previous Part #
7104074	7092757 [C]	Dual 40Gb/Sec (4x) QDR InfiniBand Host Channel Adapter Module M3	n/a
X4242A	375-3696 [C]	Dual 40Gbps InfiniBand 4x QDR PCI Express Low Profile Host Channel Adapter	n/a
X4242A	7092767 [C]	Dual 40Gbps InfiniBand 4x QDR PCI Express Low Profile Host Channel Adapter	n/a
X6000A 5 [S]	375-3424 [C]	PCI Express Sun Crypto Accelerator 6000	n/a
X6000A-N [S]	375-3424 [C]	PCI Express Sun Crypto Accelerator 6000	n/a
n/a	7046442 [C]	Dual 40Gb/Sec (4x) QDR InfiniBand Host Channel Adapter Module M3	n/a

5 Option X6099A (IPsec enabler CD) is required to enable the adapter's support for IPsec acceleration

Disk Backplane
Option #	Manufacturing Part #	Description	Previous Part #
n/a	511-1435 [F]	8-Slot Disk Backplane	n/a
n/a	7053717	8-Slot Disk Backplane Assembly	n/a
n/a	330-5301	Grey 2U Backplane Retainer Clip	n/a

Disks
Option #	Manufacturing Part #	Description	Previous Part #
7107550	7077233 [C]	400GB Solid State SATA Drive Assembly	n/a
	7076379	400GB 2.5" SATA-3 Solid State Drive Intel SSDSC2BA400G3S [ITVSC2BA3SUN400]	n/a
	541-2123	Marlin 2.5" Bracket	n/a
SE6X3K11Z	542-0287 [C]	600GB - 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks;	n/a
	390-0488	Hitachi HUC106060CSS600 [H106060SDSUN600G] (600GB - 10000 RPM - SAS Disk)	n/a
	390-0491	Seagate ST9600205SS [ST960005SSUN600G](600GB 10000 RPM SAS Disk)	n/a
	7045228	Hitachi HUC109060CSS600 [H109060SESUN600G] (600GB - 10000 RPM - SAS Disk)	n/a
	541-2123	Marlin 2.5" Bracket	n/a
7101423 [S]	7017183 [C]	100GB Solid State SATA Drive Assembly	n/a
	7017177	Intel SSDSA2BZ100G3 [Inquiry Unknown] (100GB - 2.5" Solid State - SATA Disk)	n/a
	541-2123	Marlin 2.5" Bracket	n/a
7101469 [S]	7017184 [C]	300GB Solid State SATA Drive Assembly	n/a
	7017181	Intel SSDSA2BZ300G3 [Inquiry Unknown] (300GB - 2.5" Solid State - SATA Disk)	n/a
	541-2123	Marlin 2.5" Bracket	n/a
SE6X3G12Z [S]	542-0388 [C]	300GB - 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:	n/a
	390-0487	Hitachi HUC106030CSS600 [H106030SDSUN300G] (300GB - 10000 RPM - SAS Disk)	n/a
	390-0490	Seagate ST9300605SS [ST930005SSUN300G](300GB 10000 RPM SAS Disk)	n/a
	7045226	Hitachi HUC109030CSS600 [H109030SESUN300G] (300GB - 10000 RPM - SAS Disk)	n/a
	541-2123	Marlin 2.5" Bracket	n/a

Ethernet
Option #	Manufacturing Part #	Description	Previous Part #
7100477	7070195 [C]	Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP	7048474 [C]
7100481	7070202 [C]	Dual Port GbE PCI Express 2.0 Low Profile Adapter, MMF	7014747 [C]
7100488	7070006 [C]	Dual 10-Gigabit Base-T PCI Express Gen2	7014776 [C]
SE3X7XA1Z	501-7489 7 [C]	10GbE XAUI Card	n/a
SE3X7XT1Z	375-3301 [C]	10Gb/sec XFP Optical Transceiver Multi Mode Short Range (SR)	n/a
SE3X7XT1Z	7058828 [C]	10Gb/sec XFP Optical Transceiver Multi Mode Short Range (SR)	375-3301 [C]
X1109A-Z	7051223 [C]	Dual 10-Gigabit PCI Express Ethernet SFP+ LP	375-3617 [C]
X2124A-N	7326504 [C]	10Gbps QDR InfiniBand/40Gbps Ethernet QSFP Transceiver	135-1204 [C]
X2129A-N	530-4449 [C]	10Gb/Sec Short Wave SFP+ Transceiver	n/a
X5562A-Z	135-1205 [C]	10Gb/Sec Long Wave SFP+ Transceiver	n/a
7105381 [S]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - SR
7105381 [S]	7053422 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - SR	375-3681 [C]
7105382 [S]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - Direct Attach
7105382 [S]	7053423 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - Direct Attach	375-3682 [C]
SE3X7XT2Z [S]	375-3495 [C]	10Gb/Sec XFP Optical Transceiver Single Mode Long Range (LR)	n/a
SG-XPCIEFCOE2-Q-SR [S]	7053422 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - SR	375-3681 [C]
SG-XPCIEFCOE2-Q-TA [S]	7053423 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - Direct Attach	375-3682 [C]
X4447A-Z-N [S]	7055021 [C]	Quad Port GbE PCI Express, UTP	511-1422 [C]
X4447A-Z-N [S]	371-2207	Bracket Low-Profile	n/a
X7281A-2-N [S]	7056733 [C]	PCI Express Dual Gigabit Ethernet MMF	371-0904 [C]
n/a	135-1204 [C]	10Gb/Sec QDR InfiniBand / 40Gb/Sec Ethernet QSFP Transceiver	n/a
n/a	371-0904 [C]	PCI Express Dual Gigabit Ethernet MMF	n/a
n/a	375-3617 [C]	Dual 10-Gigabit Ethernet SFP+ LP	n/a
n/a	375-3681 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - SR	n/a
n/a	375-3682 [C]	Dual 10-Gigabit Ethernet PCI Express LP SFP+ FCoE CNA - Direct Attach	n/a
n/a	511-1422 [C]	Quad Port GbE PCI Express, UTP	n/a
n/a	371-2207	Bracket Low-Profile	n/a
n/a	7014741 [C]	Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP	n/a
n/a	7014747 [C]	Dual Port GbE PCI Express 2.0 Low Profile Adapter, MMF	n/a
n/a	7014776 [C]	Dual 10-Gigabit Base-T PCI Express Gen2	n/a
n/a	7048474 [C]	Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP	7014741 [C]

7 Requires one XFP Transceiver

Fan
Option #	Manufacturing Part #	Description	Previous Part #
n/a	541-4124 [F]	Fan Board Assembly	n/a
	330-5243	Fan Board Cover	n/a
	511-1434	Fan Board	n/a
n/a	541-4222 [C]	Fan Assembly	n/a
n/a	371-4613	60×28mm 10400/9500 RPM Dual Fan	n/a

Fibre Channel
Option #	Manufacturing Part #	Description	Previous Part #
7101674	7023303 [C]	Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, QLogic	n/a
7101676	7023325 [C]	Pair of 16Gbps Short Wave SFP+	n/a
7101676	7023324	16Gb/Sec Short Wave SFP+ Transceiver, QLogic	n/a
7101678	7023315 [C]	Pair of 10Gbps Short Wave SFP+	n/a
7101678	7023316	10Gb/Sec Short Wave SFP+ Transceiver, QLogic	n/a
7101684	7023036 [C]	Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, Emulex	n/a
7101686	7023059 [C]	Pair of 16Gbps Short Wave SFP+	n/a
7101686	7023053	16Gb/Sec Short Wave SFP+ Transceiver, Emulex	n/a
7105392	8Gigabit/Sec PCI Express Dual FC Host Adapter for EU Countries
7105392	7053434 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter, Emulex	371-4306 [C]
SG-XPCIE2FC-QF8-N 9	371-4325 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	n/a
7101688 [S]	7023057 [C]	Pair of 10Gbps Short Wave SFP+	n/a
7101688 [S]	7023046	10Gb/Sec Short Wave SFP+ Transceiver, Emulex	n/a
SG-XPCIE2FC-EM8-N 10 [S]	7053434 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter, Emulex	371-4306 [C]
n/a	371-4306 [C]	8Gigabit/Sec PCI Express Dual FC Host Adapter	n/a

9 Recommended that this card be installed in upper slots 3, 4, or 5
10 Recommended that this card be installed in upper slots 3, 4, or 5

I/O
Option #	Manufacturing Part #	Description	Previous Part #
n/a	541-4084 [C]	2-Slot X8/XAUI Riser Assembly	n/a
	341-4139	PCI Filler Panel	n/a
	350-1413	PCI Express Riser	n/a
	511-1613	XAUI Riser	n/a
n/a	541-4085 [C]	2-Slot X8/X16 PCI Express Riser Assembly	n/a
	341-4139	PCI Filler Panel	n/a
	511-1614	PCI Express Riser	n/a
	541-2531	Bracket	n/a
n/a	7047128 [C]	2-Slot X8/XAUI Riser Assembly	541-4084 [C]
	341-4139	PCI Filler Panel	n/a
	350-1413	PCI Express Riser	n/a
	7047129	XAUI Riser	511-1613
n/a	7047131 [C]	2-Slot X8/X16 PCI Express Riser Assembly	541-4085 [C]
	341-4139	PCI Filler Panel	n/a
	541-2531	Bracket	n/a
	7047178	PCI Express Riser	511-1614

Memory
Option #	Manufacturing Part #	Description	Previous Part #
7104199	16GB Memory Expansion (1 × 16GB) Option
7104199	7042210 [C]	16GB DDR3L-1600/PC3L-12800 DIMM (runs at 1066 MHz)	n/a
7104201	32GB Memory Expansion (1 × 32GB) Option
7104201	7042211 [C]	32GB DDR3L-1066/DDR3L-1333 DIMM	n/a
7101696 [S]	8GB Memory Expansion (2 × 4GB) Option
7101696 [S]	7014642 [C]	4GB DDR3L-1333/PC3L-10600 DIMM	n/a
7101697 [S]	16GB Memory Expansion (2 × 8GB) Option
7101697 [S]	7014640 [C]	8GB DDR3L-1333/PC3L-10600 DIMM	n/a
7101698 [S]	32GB Memory Expansion (2 × 16GB) Option
7101698 [S]	7020577 [C]	16GB DDR3L-1066/PC3L-10600 DIMM	n/a
7104197 [S]	8GB Memory Expansion (1 × 8GB) Option
7104197 [S]	7042208 [C]	8GB DDR3L-1600/PC3L-12800 DIMM	n/a

Miscellaneous
Option #	Manufacturing Part #	Description	Previous Part #
n/a	350-1562	Clear Plastic Air Duct	n/a

Power
Option #	Manufacturing Part #	Description	Previous Part #
n/a	300-2235 [C]	Type A249 1100/1200 Watt AC Input Power Supply	n/a
n/a	300-2304 [C]	Type A249A 1100/1200 Watt AC Input Power Supply	300-2235 [C]
n/a	541-4223 [F]	Power Distribution Assembly	n/a
	341-3166	Bus Bar Left	n/a
	341-3167	Bus Bar Right	n/a
	511-1437	Horizontal Power Distribution Board	n/a
	371-2484 11	PDB Signal Cable	n/a
	511-1513	Vertical Power Distribution Board	n/a
n/a	7049253 [F]	Power Distribution Assembly	541-4223 [F]
	341-3166	Bus Bar Left	n/a
	341-3167	Bus Bar Right	n/a
	7049252	Vertical Power Distribution Board	n/a
	7051687	Horizontal Power Distribution Board	511-1437
	371-2484 12	PDB Signal Cable	n/a
n/a	7081590 [C]	Type A249A 1100/1200 Watt AC Input Power Supply	300-2304 [C]

11 This part is also included in the cable kit FRU packaged part
12 This part is also included in the cable kit FRU packaged part

Rack
Option #	Manufacturing Part #	Description	Previous Part #
n/a	371-2740 [C]	1U/2U Snap-In Slide Rail Rackmount Kit, 730mm	n/a
n/a	371-2742 [C]	1U/2U Cable Management Arm	n/a

Removable Media
Option #	Manufacturing Part #	Description	Previous Part #
n/a	541-2732 [C]	USB Assembly	n/a
	330-4418	DVD Tray	n/a
	341-4072	DVD Filler Panel	n/a
	501-7698	USB Board	n/a
n/a	541-3493 [C]	Slot-Load SATA DVD-Writer/CD-Writer - USB Board Assembly	n/a
	330-5056	DVD Tray	n/a
	390-0442	8x Slot-Load SATA DVD-Writer/24x CD-Writer	n/a
	390-0443	8x Slot-Load SATA DVD-Writer/24x CD-Writer	n/a
	390-0454	8x SATA DVD Writer/24x CD-Writer	n/a
	390-0486	8x Slot-Load SATA DVD-Writer/24x CD-Writer	390-0443
	501-7698	USB Board	n/a
n/a	7057476 [C]	Slot-Load SATA DVD-Writer/CD-Writer - USB Board Assembly	n/a
	330-5056	DVD Tray	n/a
	501-7698	USB Board	n/a
	7045772	8x Slot-Load SATA DVD-Writer/24x CD-Writer	n/a
	7066500	DVD Tray	n/a
n/a	7070425 [C]	Slot-Load SATA DVD-Writer/CD-Writer - USB Board Assembly	n/a
	330-5056	DVD Tray	n/a
	501-7698	USB Board	n/a
	7045772	8x Slot-Load SATA DVD-Writer/24x CD-Writer	n/a
	7066500	DVD Tray	n/a
n/a	7079141 [C]	Tray-Load SATA DVD-Writer/CD-Writer - USB Board Assembly	n/a
	501-7698	USB Board	n/a
	7071296	8x Tray-Load SATA DVD-ROM Writer / 24x CD-ROM Writer	n/a
	7079137	DVD Tray	n/a
	7089963	8x Tray-Load DVD-ROM/24-x CD-ROM Writer (Gen5)	n/a
	7309891	8x Tray-Load DVD-ROM/24x CD-ROM Writer (Gen6)	n/a

SCSI
Option #	Manufacturing Part #	Description	Previous Part #
7105387	8-Port 6Gbps SAS-2 PCI Express HBA
7105387	7047853 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	375-3641 [C]
7107092	7069200 [C]	800GB PCI Express Flash Accelerator F80 SAS HBA	n/a
7104482 [S]	7070787 [C]	Flash Accelerator F40 400GB Solid State Memory	7026993 [C]
7105384 [S]	Dual-Channel Ultra320 LVD SCSI PCI Express Adapter for EU Countries
7105384 [S]	7050790 [C]	Dual-Channel Ultra320 LVD SCSI PCI Express Adapter	375-3357 [C]
SGX-SAS6-EXT-Z 13 [S]	7047853 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	375-3641 [C]
SGX-SAS6-R-INT-Z 14 15 [S]	7047503 [C]	8-Port 6Gbps SAS-2 RAID PCI Express HBA, B4 ASIC	375-3701 [C]
SGX-SAS6-R-INT-Z 14 15 [S]	7050794 [C]	6Gbps SAS-2 RAID PCI Battery Module, BBU08	371-4982 [C]
SGXPCIE2SCSIU320-N [S]	7050790 [C]	Dual-Channel Ultra320 LVD SCSI PCI Express Adapter	375-3357 [C]
n/a	371-4982 [C]	6Gbps SAS-2 RAID PCI Battery Module, BBU08	n/a
n/a	375-3357 [C]	Dual-Channel Ultra320 LVD SCSI PCI Express Adapter	n/a
n/a	375-3641 [C]	8-Port 6Gbps SAS-2 PCI Express HBA (LSI)	n/a
n/a	375-3701 [C]	8-Port 6Gbps SAS-2 RAID PCI Express HBA, B4 ASIC	n/a
n/a	7026993 [C]	Flash Accelerator F40 400GB Solid State Memory	n/a

13 For external cable routing reasons this card must be installed in slot 3, slot 4 or slot 5.
14 If SAS cabling for X-Option SGX-SAS6-R-INT-Z is needed, order X-Option SE3X4A11Z SAS Cable Kit.
15 For thermal reasons the RAID HBA needs to be in slot 3.

System Board
Option #	Manufacturing Part #	Description	Previous Part #
n/a	7096741 [F]	8-Core 2.85GHz System Board Assembly (reworked 7047134)	n/a
	350-1440	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	7047135	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a
n/a	7096745 16 [F]	8-Core 2.85GHz System Board Assembly (reworked 7063388)	n/a
	350-1440	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	7063382	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a
n/a	7097402 [F]	8-Core 2.85GHz System Board Assembly (reworked 7015924)	n/a
	350-1440	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	7015696	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a
n/a	7321781 [F]	8-Core 2.85GHz System Board Assembly	n/a
	350-1440	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	7321738	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a
n/a	7015924 [F] [S]	8-Core 2.85GHz System Board Assembly	n/a
	350-1440	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	7015696	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a
n/a	7047134 [F] [S]	8-Core 2.85GHz System Board Assembly	7015924 [F] [S]
	350-1440	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	7047135	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a
n/a	7063388 17 [F] [S]	8-Core 2.85GHz System Board Assembly	n/a
	350-1440	Mounting Tray	n/a
	371-2210 [C]	3V Lithium Coin Cell Battery	n/a
	7063382	System Board	n/a
	525-2146 [F]	SSCC NVRAM	n/a

16 Requires System Firmware 8.4.2.d (or higher)
17 Requires System Firmware 8.4.2.d (or higher)

System Service Processor
Option #	Manufacturing Part #	Description	Previous Part #
n/a	541-4693 [C]	Service Processor Assembly	n/a
	350-1614	Service Processor Cover	n/a
	511-1336	AST2200 Service Processor	n/a
n/a	7053715 [C]	Service Processor Assembly	541-4693 [C]
	350-1614	Service Processor Cover	n/a
	7053714	AST2200 Service Processor	n/a

Adirondack Networks Hardware Warranty:

Depot warranty includes telephone support and defective part replacement. Warranty period is 30 days from date of sale on computer components, configured refurbished workstations and servers. Telephone support and RMA department assistance is available between the hours of 9:00 a.m. and 5:00 p.m. (Eastern Standard Time), Monday through Friday, excluding holidays. Warranty is void on items termed "as is" basis.

Extended Hardware Maintenance Warranty:

The extended warranty period must be purchased in 12-month increments. An extended warranty is available and may be purchased at the time of sale, during, or at the end of an existing warranty time period.

Warranty Repair:

If a component part or system becomes defective outside of the warranty period, Adirondack Networks shall charge a nominal fee for evaluation and repair of the defective part. Any replacement or additional parts needed for repair shall be billed to the customer. Customers will be given a quote on repair costs prior to a repair being completed.

GET AN MAINTENANCE QUOTE

Sell us your IT Equipment

We Buy Used Computer & Networking Hardware

If your company has IT equipment that is no longer needed, we are constantly buying new, used, decommissioned or off- lease equipment. Contact Adirondack Networks for a competitive buy-out offer or trade-in allowance and let us help you recover your technology assets and get a return on your original investment.

GET A BUY-OUT QUOTE

About us

Adirondack Networks is a leading provider of new, refurbished and used Oracle Sun SPARC T4-1 Server hardware. We specialize in Legacy Sun Servers and many other computer server and networking hardware products. Adirondack Networks delivers the best technology and networking products at the best prices. Through our global network of partners, we are able to deliver hardware like the Oracle Sun SPARC T4-1 Server to our customers more efficiently and more cost effectively than mainline distribution. If you are looking to get the job done ahead of schedule and under budget, you are looking for us. Find hardware, components and upgrades at the lowest prices. Adirondack Networks continues to provide hard-to-find discontinued or end-of-life computer servers, networking equipment and replacement parts and can save your company up to 85% off list price.

Contact us if you have questions or need more information on Part#:

Adirondack Networks also offers extended warranties on the Oracle Sun SPARC T4-1 Server and other Legacy Sun Servers. Contact us for options and pricing.

Oracle Sun SPARC T4-1 Server

IN STOCK; READY TO MOVE

About the Oracle Sun SPARC T4-1 Server

Component List

SPARC-T4-1 Component List

Adirondack Networks Hardware Warranty:

Extended Hardware Maintenance Warranty:

Warranty Repair:

Sell us your IT Equipment

We Buy Used Computer & Networking Hardware

About us

Sun X-Options & Parts

Sun Workstations

Sun Disk Storage Arrays

Systems

Memory

Storage Devices

Input Devices

Output Devices

Networking

Software

Office Machines

Communication

Contact Us

IT Products

IT Solutions

IT Services

Help & Support

For a Limited Time
GET 3 MONTHS FREE!

Oracle Sun SPARC T4-1 Server

IN STOCK; READY TO MOVE

About the Oracle Sun SPARC T4-1 Server

Component List

SPARC-T4-1 Component List

Adirondack Networks Hardware Warranty:

Extended Hardware Maintenance Warranty:

Warranty Repair:

Sell us your IT Equipment

We Buy Used Computer & Networking Hardware

About us

Contact Us

IT Products

IT Solutions

IT Services

Help & Support

For a Limited Time GET 3 MONTHS FREE!

For a Limited Time
GET 3 MONTHS FREE!
