PRIMERGY RX2520 M1 Rack Server
The Fujitsu PRIMERGY RX2520 M1 is an efficient and scalable platform featuring the latest Intel Xeon processor E5-2400 v2 product family and up to 192 GB RAM.
Manufacturer Fujitsu Part Number(s): RX2520-M1
Adirondack Networks offers complete configurations as well as individual parts and upgrades for this model. For pricing on new or refurbished PRIMERGY RX2520 M1 Rack Servers, upgrades or parts, please contact us.
About the PRIMERGY RX2520 M1 Rack Server
Chipset
- Intel C600 (Patsburg A)
Mainboard Type
- D3169
Product Type
- Dual Socket Rack Server
Processor
- Intel Xeon processor E5-2400 v2 product family
Memory
- 2 GB - 192 GB, DIMM (DDR3)
Memory Protection
- Advanced ECC
- Memory Scrubbing
- SDDC
Drives (Optional)
- DVD supermulti
- Ultraslim
- SATA I
- LTO5HH Ultrium, 140 MB/s, 1,500 GB, SAS 6Gb/s
- RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0
- LTO6HH Ultrium, 160 MB/s, 2,500 GB, SAS 6Gb/s
- LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/s
PCI-Express 3.0 x8
- 6 x Low profile
PCI-Express 2.0 x4 (mech. x8)
- 1 x Low profile
Slot Notes
- The number of PCIe slots depends on the number of CPUs:
- 5x PCIe x8 Gen 3 (2x CPU1; 3x CPU2; mechanical x8)
- 1x PCIe x4 Gen 2 (PCH; mechanical x8)
- Internal Slots
- 1x PCIe x8 Gen 3 (CPU1; mechanical x8)
Accessible Drive Bays
- 1 x 5.25/0.5-inch for ODD
- 1 x 5.25/0.5-inch for Local Service Display
- 1 x 3.5/1.6-inch for backup devices
- 1 x 5.25/1.6-inch for backup devices
Optional Accessible Drives
- Up to 1 x ODD and/or backup device
- All possible options described in relevant system configurator
Storage Drive Bays
- 2.5-inch base unit (max. 16 x 2.5) or 3.5-inch base unit (max. 12 x 3.5)
- Max 8 x 3.5-inch
- Max 12 x 3.5-inch
- Max 16 x 2.5-inch
I/O Controller Onboard
- Intel® C600, 1 x SATA channel for ODD
- 4 port for internal 3 Gbit/s SATA and 3 Gbit/s SAS (as upgrade option with SAS enabling key) for HDDs with RAID 0/1/10 (Intel C600)
- Intel® Ethernet Controller I210
- 2 x 1Gbit/s Ethernet Controller (10/100/1000 Mbit/s)
- IPMI 2.0 compatible, Integrated Remote Management Controller (iRMC S4, 256 MB attached memory incl. graphics controller)
Trusted Platform Module (TPM)
- Infineon / TPM 1.2 module; TCG compliant (option)
Power Supply Configuration
- 1x hot-plug power supply or 2x hot-plug power supply for redundancy
Active Power
- 643 W
Rack (W x D x H)
- 482.6 mm (Bezel) / 445mm (Body) x 770 x 86.9 mm
Mounting Depth Rack
- 735 mm
Weight
- Up to 25 kg
